small wind turbine slip ring ,capsule slip ring ,3 Current 30A

Product Categories
Shenzhen Flyda Technology Co., Ltd
Contact Now

small wind turbine slip ring ,capsule slip ring ,3 Current 30A

Place of Origin : Guangdong, China

Brand Name : FLYDA

Certification : CE, ROHS

Model Number : GC022-3P30

MOQ : 10PC

Price : $12-$20

Packaging Details : standard packing with box

Delivery Time : 3-7 days after got the payment

Payment Terms : 100% prepaid

Supply Ability : 10000 Piece/Pieces per week

Number of Circuits : 3

Current Rating : 30A, per ring, maximum

Lead Wire : UL Teflon Awg12,color-coded,

Voltage : 240 VDC / 440 VAC

Noise : <10mΩ

Protection : IP51

Contact Now

Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Flyda
  • Model Number: GC022-3P30
  • wire: 3
  • Contact Material: Precious Metal:Gold-Gold
  • Housing Material: Engineer plastic
  • Working life: 80 million
  • Current: 30A
  • Certification: CE .ROHS

Packaging & Delivery

Product Description

Pls contact us for precise datasheet

Capsule slip rings can transmit high current and high speed with compact design. Its low contact resistance and optimized heat dissipation structure ensure slip ring to work stably for a long time, all of this can avoid slip ring to strike fire. It uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections.

OD=22mm Capsule slip ring-Shenzhen Flyda Technology Co., Limited

Advantage
1. Low torque minimizes system torque budget
2. Compact design to fit in the most demanding space.
3. Smooth running
4. Low electrical noise
5. Quick shipment per your urgent requirement
6. 360 degree continuous rotation
7. High bandwidth transfer capability

Features
A. 3 circuits models
B. 30 amps,240VAC/DC per circuit
C. Speed up to 300 rpm continuous
D. Gold-Gold contacts makes long life time
E. Compatible with data bus protocols
F. Sealed units are also available
G. Flexible, color-coded, silver-plated, insulated lead wires
H. Transfers analog and digital signals

Wires 3 wires Current 30A
Voltage 240 VDC/VAC Max speed 350RPM
Overall diameter 22mm(0.98") Length
Contact Material Precious Metal:gold-gold Contact Resistance <150mOhm(AWG26#,250mm)
Housing Material Plastics Torque 0.04N.m
Working life depends on working speed Electrical noise <10mΩ
Dielectric strength 600VDC@50Hz Lead Wire UL Teflon® Awg26
Insulation resistance 1000MΩ@500VDC Lead Lengths 250mm
Operating Temp. -40°C to 80°C Protection IP51
Mechanical vibratio MIL-SID-810E Humidity 10% to 90% RH
Materials Lead Free,RoHS compliant CE Certified YES

small wind turbine slip ring ,capsule slip ring ,3 Current 30A

small wind turbine slip ring ,capsule slip ring ,3 Current 30A

Company Information

1. Flyda has more than 10 years experience on research & production of slip ring;
2. Fast delivery, Flyda assure the delivery speed above market level;
3. Best after-sale service, Flyda cherrish every customer, no matter sample order or mass order
4. OEM welcome
small wind turbine slip ring ,capsule slip ring ,3 Current 30A
small wind turbine slip ring ,capsule slip ring ,3 Current 30A
Packaging & Shipping

1. Package: polybag inside, standard carton

2.shipping: 7-10working days after payment, by DHL/FEDEX/UPS/EMS/by sea

Applications

  • CCTV Monitoring System.
  • Electrical test equipment.
  • Medical equipment.
  • Rotary table
  • Robotics
  • Laboratory equipmen
  • Manufacturing and process control equipment
  • and so on...
